Remote Control Mode Setup
! Default setting: 1
This sets this receiver’s remote control mode
to prevent erroneous operation when multiple
units of the receiver are being used.
1 Select ‘Remote Control Mode Setup’
from the Other Setup menu.
2 Select the Remote Control Mode
setting you want.
3 Select ‘OK’ to change the remote
control mode.
4 Follow the instructions on the screen
to change the remote control’s setting.
See Operating multiple receivers on page 74.
5 When you’re finished, press RETURN.
You will return to the Other Setup menu.
Flicker Reduction Setup
! Default setting: OFF
The GUI screen’s resolution can be increased.
If you feel the GUI screen is hard to see, try
changing this setting. Note that the resolution
in this setting only affects the GUI screen; it has
no influence on the video output.
1 Select ‘Flicker Reduction Setup’ from
the Other Setup menu.
2 Select the Flicker Reduction setting you
want.
3 When you’re finished, press RETURN.
You will return to the Other Setup menu.
RF Remote Setup
SC-LX85 only
! Default setting: OFF
The CU-RF100 can be used to operate the
receiver by RF communications. To do so, set
the RF Remote setting to ON. When ON is set
here, the receiver can be operated even when
the receiver is in the standby mode.
1 Select ‘RF Remote Setup’ from the
Other Setup menu.
2 Select the RF Remote setting you want.
3 When you’re finished, press RETURN.
You will return to the Other Setup menu.
EXTENSION Setup
SC-LX75 only
! Default setting: OFF
A separately sold the CU-RF100 can be used to
operate the receiver by RF communications. To
do so, set the EXTENSION setting to ON. When
ON is set here, the receiver can be operated
even when the receiver is in the standby mode.
1 Select ‘EXTENSION Setup’ from the
Other Setup menu.
2 Select the EXTENSION setting you
want.
3 When you’re finished, press RETURN.
You will return to the Other Setup menu.
Multi Channel Input Setup
SC-LX85 only
You can adjust the level of the subwoofer for
a multi-channel input. Also, when the multi-
channel input is selected as an input function,
you can display the video images of other input
functions. In the Multi Channel Input Setup, you
can assign a video input to the multi-channel
input.
1 Select ‘Multi Ch In Setup’ from the
Other Setup menu.
2 Select the ‘SW Input Gain’ setting you
want.
! 0dB – Outputs sound of the subwoofer at the
level originally recorded on the source.
! +10dB – Outputs sound of the subwoofer at
the level increased by 10 dB.
En
92
13 The System Setup and Other Setup menus
! Pairing Bluetooth Setup – Use to pair a
Bluetooth ADAPTER and Bluetooth wireless
technology device (page 43).
5 Make the adjustments necessary for
each setting, pressing RETURN to confirm
after each screen.
Auto Power Down
The power can be set to turn off automatically if
no operation has been performed for a specific
amount of time with no audio or video signals
being input to the receiver. When using ZONE
2 or ZONE 3, the ZONE 2 or ZONE 3 power can
also be set to turn off, but for ZONE 2 or ZONE
3 the power turns off automatically after the
amount of time set here even if signals are
being input or operations have been performed.
Different times can be set for the main zone,
ZONE 2 and ZONE 3.
1 Select ‘Auto Power Down’ from the
Other Setup menu.
2 Select the zone you want to set and set
the time after which the power turns off.
! MAIN – The time can be selected from
among “15 min”, “30 min”, “60 min” and
“OFF”. The power turns off after there has
been no signal and no operation for the
selected time.
! ZONE 2 – The time can be selected from
among “30 min”, “1 hour”, “3 hours”,
“6 hours”, “9 hours” and “OFF”. The power
turns off after the selected time.
! ZONE 3 – The time can be selected from
among “30 min”, “1 hour”, “3 hours”,
“6 hours”, “9 hours” and “OFF”. The power
turns off after the selected time.
Note
! Depending on the connected devices, the
Auto Power Down function may not work
properly due to excessive noise or other
reasons.
Volume Setup
You can set the maximum volume of this
receiver or specify what the volume level will be
when the power is turned on.
1 Select ‘Volume Setup’ from the
Other Setup menu.
2 Select the Power ON Level setting you
want.
The volume can be set so that it is always set
to the same level when the receiver’s power is
turned on.
! LAST (default) – When the power is turned
on, the volume is set to the same level as
when the power was last turned off.
! “---” – When the power is turned on, the
volume is set to minimum level.
! –80.0dB to +12.0dB – Specify the volume to
be set when the power is turned on, in steps
of 0.5 dB.
It is not possible to set a volume level greater
than the value specified at Volume Limit setup
(see below).
3 Select the Volume Limit setting you
want.
Use this function to limit the maximum volume.
The volume cannot be increased above the level
set here, even by operating MASTER VOLUME
button (or the dial on the front panel).
! OFF (default) – The maximum volume is not
limited.
! –20.0dB/–10.0dB/0.0dB – The maximum
volume is limited to the value set here.
4 Select the Mute Level setting you
want.
This sets how much the volume is to be turned
down when MUTE is pressed.
! FULL (default) – No sound.
! –40.0dB/–20.0dB – The volume will be
turned down to the level specified here.
5 When you’re finished, press RETURN.
You will return to the Other Setup menu.
