Connecting your equipment
17
En
02
02
Connecting your TV with no HDMI input
This diagram shows connections of a TV (with no HDMI
input) and DVD player (or other playback component) to the
receiver.
• With these connections, the picture is not output to the
TV even if the DVD player is connected with an HDMI
cable. Connect the DVD player’s video signals using a
composite or component cable.
• Connect using an HDMI cable to listen to HD audio on the
receiver. Do not use an HDMI cable to input video signals.
Depending on the video component, it may not be
possible to output signals connected by HDMI and other
methods simultaneously, and it may be necessary to
make output settings. Please refer to the operating
instructions supplied with your component for more
information.
• If both TV and player has a component video jacks, you
can connect these too. See Using the component video
jacks on page 20 for more on this.
• In order to listen to the audio from the DVD player that is
connected to this receiver using an optical cable or a
coaxial cable, first, switch to the DVD input, then press
SIGNAL SEL to choose the audio signal O2 (OPTICAL2) or
C1 (COAXIAL1) (see Selecting the audio input signal on
page 26).
HDMI
VIDEO
COMPONENT
VIDEO
DVR/
BDR
L
R
R
L
YP
B PR
COAXIAL
AUDIO
PRE OUT
ANTENNA
OPTICAL
ASSIGNABLE
ASSIGN
ABLE
ASSIGNABLE
OUT
A
DVR/BDR
OUT
CD-R/TAPE
L
R
IN
(
CD
)
1
SUBWOOFER
IN IN
CD
MONITOR
OUT
TV/SAT
IN
BD
IN
OUT
IN
DVD IN
IN
TV/SAT
BD
IN
DVD
(
DVD
)
IN
1
MONITOR
OUT
(
DVR /
BDR
)
IN
2
DVR/BDR IN
DVD IN
BD IN
VIDEO 1 IN
(
TV/SAT
)
IN
1
(
CD-R/TAPE
)
IN
2
FM UNBAL
75
(
OUTPUT 5
V
0.1 A MAX
)
ADAPTER PORT
AM LOOP
FRONT
RL
CENTER
RL
DIGITAL AUDIO OUT ANALOG AUDIO OUT
OPTICAL
RL
DIGITAL AUDIO OUTANALOG AUDIO OUT
OPTICAL COAXIAL
VIDEO IN
VIDEO OUT
HDMI OUT
Select one
TV
DVD player
Select one
This connection is
required in order to
listen to the sound of
the TV over the
receiver.
VSX-826
VSX-821_826_SYXCN_En.book 17 ページ ２０１１年２月９日 水曜日 午後３時４８分
