Resetting the main unit
Use this procedure to reset all the receiver’s settings to the
factory default. Use the front panel controls to do this.
1
Switch the receiver into standby.
2
While holding down BAND, press and hold
STANDBY/ON
for about two seconds.
3
When you see RESET? appear in the display, press AUTO
SURROUND/STREAM DIRECT.
OK? shows in the display.
4
Press ALC/STANDARD SURR to confirm.
OK appears in the display to indicate that the receiver has
been reset to the factory default settings.
•If the Control with HDMI function is set to ON, you may
not be able to reset the unit. In this case, reset either by
turning OFF the Control with HDMI function, or by
putting the unit into standby mode by turning off the
power of all the connected devices, and resetting after the
HDMI indicator on the front panel turns off.
Cleaning the unit
• Use a polishing cloth or dry cloth to wipe off dust and dirt.
• When the surface is dirty, wipe with a soft cloth dipped in
some neutral cleanser diluted five or six times with water,
and wrung out well, and then wipe again with a dry cloth.
Do not use furniture wax or cleansers.
• Never use thinners, benzine, insecticide sprays or other
chemicals on or near this unit, since these will corrode
the surface.
Specifications
Audio section
Rated power output
Front, Center, Surround
. . . . . . . . . . . . . . . . . . 130 W per channel (1 kHz, 6
Ω
, 1 %)
. . . . . . . .100 W per channel (20 Hz to 20 kHz, 8
Ω
, 0.09 %)
Total Harmonic Distortion
. . . . . . . . . . . . . . . . 0.06 % (20 Hz to 20 kHz, 8
Ω
, 50 W/ch)
Frequency response (LINE Pure Direct mode)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Hz to 100 kHz dB
Guaranteed speaker impedance (VSX-826) . . . . . .6
Ω
to 16
Ω
Guaranteed speaker impedance (VSX-821)
FRONT : A, B. . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Ω
to 16
Ω
FRONT : A+B . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Ω
to 16
Ω
SURROUND, CENTER . . . . . . . . . . . . . . . . . . . . .6
Ω
to 16
Ω
Input (Sensitivity/Impedance)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 mV/47 kΩ
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 mV/2.2 kΩ
Signal-to-Noise Ratio (IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 dB
Video section
Signal level
Composite. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 Ω)
Component Video. . . . . . . . . . . . . . . . . . . Y: 1.0 Vp-p (75 Ω)
PB, PR: 0.7 Vp-p (75 Ω)
Corresponding maximum resolution
Component Video. . . . . . . . . . . . . . . . . . . . . . 1080p (1125p)
Tuner section
Frequency Range (FM) . . . . . . . . . . . . . . 87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . . . . . . . . . . . 75 Ω unbalanced
Frequency Range (AM) . . . . . . . . . . . . . . 531 kHz to 1602 kHz
Antenna (AM) . . . . . . . . . . . . . . . . . . . . . . . . . . . Loop antenna
Digital In/Out section
HDMI terminal . . . . . . . . . . . . . . . . . . . . . . . . . Type A (19-pin)
HDMI output type . . . . . . . . . . . . . . . . . . . . . . . . . .5 V, 100 mA
USB terminal. . . . . . . . . . . . . . . . .USB2.0 Full Speed (Type A)
iPod terminal. . . . . . . . . . . . . . . .USB, and Video (Composite)
ADAPTER PORT terminal . . . . . . . . . . . . . . . . . . .5 V, 100 mA
Miscellaneous
Power Requirements . . . . . . .AC 220 V to 230 V, 50 Hz/60 Hz
Power Consumption . . . . . . . . . . . . . . . . . . . .500 W (VSX-826)
415 W (VSX-821)
In standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.45 W
(Control with HDMI function: OFF)
Dimensions . . . . . 435 mm (W) x 168 mm (H) x 362.5 mm (D)
Weight (without package) . . . . . . . . . . . . . . . 9.6 kg (VSX-826)
9.2 kg (VSX-821)
Furnished Parts
Microphone (for Auto MCACC setup). . . . . . . . . . . . . . . . . . .1
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Dry cell batteries (AAA size IEC R03) . . . . . . . . . . . . . . . . . . . 2
AM loop antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
iPod cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cord
Quick start guide
These operating instructions
• The specifications are applicable when the power supply
is 230 V.
• Specifications and the design are subject to possible
modifications without notice, due to improvements.
Manufactured under license from Dolby Laboratories. “Dolby”,
“Pro Logic”, “Surround EX”, and the double-D symbol are
trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent #’s: 5,451,942;
5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535;
7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and
worldwide patents issued & pending. DTS and the Symbol are
registered trademarks, & DTS-HD, DTS-HD Master Audio, and
the DTS logos are trademarks of DTS, Inc. Product includes
software. © DTS, Inc. All Rights Reserved.
