Controls and displays
7
En
01
01
10 Listening mode buttons
AUTO SURROUND/STREAM DIRECT – Switches
between Auto surround mode (page 33) and Stream
Direct playback (page 34).
ALC/STANDARD SURR – Press for standard decoding
and to switch between the modes of 2 Pro Logic II, 2
Pro Logic IIx, 2 Pro Logic IIz and NEO:6, and the Auto
level control stereo mode (page 33).
ADVANCED SURROUND – Switches between the
various surround modes (page 34).
11 MCACC SETUP MIC jack
Use to connect a microphone when performing Auto MCACC
setup (page 24).
12 AUDIO/VIDEO input terminal
See Connecting to the front panel video terminal on page 22.
13 iPod iPhone iPad/USB terminal
Use to connect your Apple iPod or USB mass storage device
as an audio source (page 22).
14 SOUND RETRIEVER AIR
When the button is pressed, the input switches to ADAPTER
and the listening mode is automatically set to S.R AIR
(page 30).
15 iPod iPhone iPad DIRECT CONTROL
Change the receiver’s input to the iPod and enable iPod
operations on the iPod (page 28).
Display
16 PHASE
Lights when the Phase Control is switched on (page 35).
17 AUTO
Lights when the Auto Surround feature is switched on
(page 33).
18 Tuner indicators
RDS – Lights when an RDS broadcast is received
(page 32).
ST – Lights when a stereo FM broadcast is being received
in auto stereo mode (page 31).
TUNE – Lights when a normal broadcast channel.
PRESET – Shows when a preset radio station is registered
or called.
MEM – Blinks when a radio station is registered.
kHz/MHz – Lights when the character display is showing
the currently received AM/FM broadcast frequency.
19 Speaker indicators
Indicates the speaker terminal, A and/or B, to which audio
signal output is currently set (page 13).
20 Sleep timer indicator
Lights when the receiver is in sleep mode (page 8).
21 PRESET information or input signal indicator
Shows the preset number of the tuner or the input signal
type, etc.
22 Character display
Displays various system information.
23 DTS indicators
DTS – Lights when a source with DTS encoded audio
signals is detected.
HD – Lights when a source with DTS-EXPRESS or DTS-
HD encoded audio signals is detected.
ES – Lights to indicate DTS-ES decoding.
96/24 – Lights when a source with DTS 96/24 encoded
audio signals is detected.
NEO:6 – When one of the NEO:6 modes of the receiver is
on, this lights to indicate NEO:6 processing (page 33).
24 Dolby Digital indicators
2D – Lights when a Dolby Digital encoded signal is
detected.
2D+ – Lights when a source with Dolby Digital Plus
encoded audio signals is detected.
2HD – Lights when a source with Dolby TrueHD
encoded audio signals is detected.
EX – Lights to indicate Dolby Digital EX decoding.
2PLII(x) – Lights to indicate 2 Pro Logic II/2 Pro Logic
IIx decoding. Light will go off during 2 Pro Logic IIz
decoding (see Listening in surround sound on page 33 for
more on this).
25 ADV.S.
Lights when one of the Advanced Surround modes has been
selected (see Using the Advanced surround on page 34 for
more on this).
26 SIGNAL SELECT indicators
DIGITAL – Lights when a digital audio signal is selected.
Blinks when a digital audio signal is selected and
selected audio input is not provided.
HDMI – Lights when an HDMI signal is selected. Blinks
when an HDMI signal is selected and selected HDMI
input is not provided.
27 Up Mix/DIMMER indicator
Lights when the Up Mix function is set to ON (page 35). Also,
lights when DIMMER is set to off.
28 DIR.
Lights when the DIRECT or PURE DIRECT mode is switched
on (page 34).
VSX-821_826_SYXCN_En.book 7 ページ ２０１１年２月９日 水曜日 午後３時４８分
