Plockmatic SR90 User Manual

5
What You Can Do with This Machine
The Booklet Maker SR90, Trimmer TR90 and Cover Feeder CF90 forms a booklet making
system that works online with the Bellini C2a/b, Martini and Bellini C1a/b.
The print-outs from the Bellini C2a/b are collected in the finisher and then transported into
the SR90 Booklet Maker to the staple area. From the CF90 Cover Feeder (optional), if
present, any type of covers, colored or black and whites, can be added to the printed set. The
Booklet Maker now jogs and then staples the set. The set is then transported further to the
folding area where the set is folded to a booklet and then fed onto the belt stacker. When a
larger number of sheets are folded an effect called creeping occurs. In order to rectify creep,
the TR90 Trimmer (optional) can be attached after the Booklet Maker. The booklets are then
transported from the Booklet Maker into the Trimmer where the trail edge will be cut off. The
booklets are then fed onto the Belt Stacker.
To facilitate undocking, a Rail (optional) can be installed under the Booklet Maker. Undocked,
or off-line, the Booklet Maker can be used as a stand-alone unit for hand feeding.
CF90 Cover Feeder
(option)
TR90 Trimmer
(option)
SR90 Booklet Maker
Rail (option)
