GENERAL INFORMATION
1.24
COMPRESSION TEST
1. Remove spark plug and install compression tester.
2. Connect high tension lead to a good ground on engine.
3. Open throttle and crank engine until maximum reading is obtained (approximately 3-5 revolutions).
AIR FILTER SERVICE
1. Remove three (3) screws on the airbox. Slide car-
buretor boot clamp off of carburetor.
2. Remove the airbox cover to expose the filter ele-
ment.
3. Carefully wash the element in soapy water and dry
it. Replace filter if necessary.
4. Lightly grease the sealing surfaces of the air filter
cover. Install cover.
5. Install three (3) screws and boot clamp.
Cylinder Compression
Service Limit 115 PSI
