ENGINE
2.1
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS
Fastener Torque
Carburetor Adaptor 20 in.lbs (2.25 Nm)
Crankcase 86 in.lbs (10 Nm)
Intake Manifold Bolts 108 in.lbs (12 Nm)
Cylinder Head Nuts 14 ft.lbs (19 Nm)
Drive Clutch Nut 29 ft.lbs (39 Nm)
Driven Clutch Nut Torque 25 ft.lbs (34 Nm)
Transmission Cover Bolts 84 in.lbs (9.5 Nm)
Flywheel 25 ft.lbs (34 Nm)
Oil Drain Bolt (Transmission) 14 ft.lbs (19 Nm)
Oil Pump Bolts 43 in.lbs (5 Nm)
Fan Housing 84 in.lbs (9.5 Nm)
Fan Bolts 84 in.lbs (9.5 Nm)
Stator Plate 84 in.lbs (9.5 Nm)
Starter Motor Bolts 84 in.lbs (9.5 Nm)
Spark Plug 11 ft.lbs (15 Nm)
SPECIAL TOOLS
PART NUMBER DESCRIPTION
0450697 Crankshaft Removal Tool (TE0210)
0450698 Flywheel Puller (TE040)
0450699 Oil Pump Drive Gear Removal Tool (TE041)
0450700 Crankcase Separating Tool (TE310)
