47
CONTROLS AND FEATURES
Controls
Parking Brake
Setting the Parking Brake
1. Squeeze the left hand brake
lever t wo or three times and
hold it.
2. Push the park brake lock (2)
into the notches on the master
cylinder body. Release the
brake lever.
3. To release the parking brake
lock, squeeze the brake lever.
It will return to its released
position.
Important Safeguards
S The parking brake may relax when left on for a long period of time.
This could cause an accident.
S Do not leave the vehicle on a hill depending on the parking
brake for more than five minutes.
S Always block the downhill side of the wheels if leaving the ATV
on a hill or park the ATV in a side hill position.
Always check to be sure that the parking brake has been
disengaged before operating the ATV. An accident could result
causing severe injury if the parking brake is left on while the ATV
is operated.
WARNING
2
