Power Electronics Standalone NB 120 User Manual

POWER ELECTRONICS
NB 120
TECHNICAL CHARACTERISTICS
23
Standalone NB 120 – US
REFERENCE
NB0600H
NB060SH
NB0900H
NB090SH
NB1200H
NB120SH
DC OUTPUT
Maximum power [kW]
60
90
120
Voltage range [V]
150 – 1000
[1]
Available connectors
CCS-1, CHAdeMO
Maximum continuous current CCS
[A]
200 (optionally, 250 or 300)
Peak current CCS [A]
[2]
350
Maximum current CHAdeMO [A]
125
Maximum number of EVs charging
simultaneously
1
1
2
AC INPUT FOR
DC OUTPUT
Power [kVA]
63
95
126
Voltage [V]
480 (3ph + N + PE) ± 10%
Power factor
> 0.99
Frequency [Hz]
60
Efficiency
95%
GENERAL
Interface
10" Touchscreen
RFID card reader
Emergency stop pushbutton
Credit / debit card reader (optional)
Protections
Isolation monitor
Surge arrester Type 2 (optional)
RCD Type A (optional) + MCB
AC charge (optional): MCB + RCD Type A + RCM
Others
Smart Fleet Management
Smart Power Balance (optional)
Meter
DC meter for DC output (optional)
Cable length [ft]
16.4 with cable management system (optionally, 25)
Enclosure / foot / glass color
White (RAL 9016) / Grey (RAL 7016) / Black
Customization
[3]
Enclosure / Foot / Glass / Logo / Display
Degree of protection
NEMA 3R
Operating temperature
From -30°C to 50°C
Relative humidity
From 4% to 95%
Maximum altitude (above sea
level)
≤ 2000 m without derating (max. 3000 m)
Communications
Ethernet + OCPP 1.6 + Wifi + 3G / 4G connectivity
Dimensions (W x D x H) [ft]
2.20 x 2.46 x 5.90
Regulation
UL 2202, NEC 625, FCC Part 15 Class A
Notes: [1] 150 - 500 Vdc for CHAdeMO.
[2] Consult with Power Electronics for more information about the connector overload capability.
[3] Consult with Power Electronics for further information.
Be aware that Power Electronics is not responsible for the charger's input power connection, nor its
installation.
