CABLE ACCESS AND CONNECTIONS
CABLE ACCESS AND CONNECTIONS
Before opening any door, the equipment must be completely isolated, without any tension. Make
sure to follow the insulation guidelines and all safety instructions indicated in the "SAFETY
INSTRUCTIONS" section. Please use all the indicated PPE.
Otherwise, you may get an electric shock.
During the connection, you must ensure the proper cable installation in the terminals of the equipment so
that there are no voltage parts accessible in this wiring and the polarity is respected
To guarantee proper electrical installation, it is very important to comply with the bend radius of
the cable. The customer must ensure that the trenches are deep enough and consistent with the
section “SITE RECOMMENDATIONS”.
Refer to the recommended tightening torque for mechanical and electrical connections in the "
TORQUE AND SCREW SIZING" section.
Power Electronics is not responsible for damages resulting from an incorrect connection.
The dimensioning of the input power cable of the charging point must be checked by a qualified
electrician. The customer is responsible for the correct sizing and execution of the corresponding
connections in accordance with the regulatory requirements applicable in the country of installation.
The customer is responsible for choosing and installing the communication cables.
The customer is responsible for the correct sizing and execution of the corresponding ground
networks in accordance with the regulatory requirements applicable in the country of installation.
Power, ground, auxiliary and communication cables are not included within Power Electronics’
scope.
MATERIAL WITHIN CUSTOMER'S RESPONSIBILITY:
The following cables and elements are not provided by Power Electronics, they are customer's
responsibility.
• AC input power cables and terminal lugs (as applicable).
• Ground input cable and terminal lug to site local ground system (as applicable).
• +/- DC power cables and terminal lugs to each Dispenser or pantograph (as applicable).
• Ground cables and terminal lugs to each Dispenser or pantograph (as applicable).
• MV switchgear wiring terminals (as applicable).
• Auxiliary power supply cable to each Dispenser or pantograph (as applicable).
• Control optical fiber to each Dispenser or pantograph (as applicable).
• Ethernet cable (CAT5e or CAT6) with RJ45 terminals OR optional multimode optical fiber to
each Dispenser (as applicable).
