Precor SPINNER SHIFT User Manual

Front Stabilizer Replacement
About
This procedure provides instruction to remove and install the Front Stabilizer.
Specifications
System Component Specification
Stabilizer fastener Torque 15.6 ft-lbs (21 N•m)
Procedure
Review entire procedure before starting.
Removal Instructions
1. Place a soft mat under the bike frame and stand the bike frame on its back resting on the
rear stabilizer and seat rail.
2. Remove and retain the two stabilizer feet.
3. Remove the front stabilizer by removing the two mounting bolts and washers using a 6
mm hex key. Retain fasteners for installation.
NOTE:The stabilizer attachment bar can slide within the mounting bracket. Make
sure the attachment bar remains in position.
Installation Instructions
2. Position the front stabilizer onto the frame and fasten using the two stabilizer mounting
bolts and washers, torque to 15.6 ft-lbs (21 N•m).
3. Install the two stabilizer feet.
4. Return bike to the upright position.
5. Make sure the bike is level and setting firmly on the floor, see "Leveling Adjustment Pro-
cedure" on page15.
6. Verify bike operation per "Operation Verification" on page7 checklist and return to ser-
vice.
53
