Primera LX2000e User Manual

Troubleshooting and Maintenance 41
2. When the cover is open the Print Head will move to the center of the printer.
Important! If it does not move to the center as shown do NOT attempt to remove the
Print Head. It can only be removed when in the position shown below!
3. Locate the white Print Head locking latch. Unlock it by flipping the hand up.
Only remove the Print Head
when it is in this position!
Print Head Locking Latch

Primera LX2000e Specifications

General

Display	-
Color display	Yes
Product color	Black
Printing colors	Black, Cyan, Magenta, Yellow
Print technology	Thermal inkjet
Maximum resolution	- DPI
Maximum print height	- mm
Minimum print length	12.7 mm
Maximum printing width	210 mm
Core diameter	76.2 mm
Maximum label width	209.6 mm
Maximum label length	0.6 m
Maximum roll diameter	152.4 mm
LED indicators	Low ink, Power
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Input current	1.7 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Certification	UL, UL-C, CE, FCC Class A

Weight and Dimensions

Depth	521 mm
Width	495 mm
Height	259 mm
Weight	20400 g
