Primera LX2000e User Manual

44 Troubleshooting and Maintenance
LED Indicator Lights
RESUME/FEED-LED on solid others off Printer Ready/Idle
RESUME/FEED-LED flashing fast (6 per second) Printer error is present -see
status monitor for more
informaton
RESUME/FEED-LED PULSES, others off Printer is busy or printing
RESUME/FEED-LED flashing slow Printer is paused by button
(50/50 on/off per second)
RESUME/FEED-LED & PAUSE/UNLOAD-LED Printer is paused by external
flashing slow (50/50 on/off per second) input from 6 pin mini din
RESUME/FEED-LED and PAUSE/UNLOAD Cover is open
-LED alternately flash
ALL LEDs flash in chase mode Printer is powering up
I. Technical Support
If you have difficulties in operating your printer, the procedures in this manual and the software
User's Guide should, in most cases, solve the problem. If you still have difficulty, contact the
Technical Support using one of the methods listed below.
Source Location
Primera Knowledge Base www.primera.com/knowledgebase.html
BarTender Software Help files Open the software. Click on the Help Menu - Contents
Email Support support@primera.eu
Phone Support
+49 (0) 611 92 777-0 (Mon - Thu 9 a.m. - 5 p.m.,
Fri 9 a.m. - 3 p.m. CET)

Primera LX2000e Specifications

General

Display	-
Color display	Yes
Product color	Black
Printing colors	Black, Cyan, Magenta, Yellow
Print technology	Thermal inkjet
Maximum resolution	- DPI
Maximum print height	- mm
Minimum print length	12.7 mm
Maximum printing width	210 mm
Core diameter	76.2 mm
Maximum label width	209.6 mm
Maximum label length	0.6 m
Maximum roll diameter	152.4 mm
LED indicators	Low ink, Power
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Input current	1.7 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Certification	UL, UL-C, CE, FCC Class A

Weight and Dimensions

Depth	521 mm
Width	495 mm
Height	259 mm
Weight	20400 g
