NB-IoT Module Series
BC95 Hardware Design
BC95_Hardware_Design Confidential / Released 9 / 51
2 Product Concept
2.1. General Description
BC95 is a series of NB-IoT module which contains four variants: BC95-B8, BC95-B5, BC95-B20 and
BC95-B28*. It is designed to communicate with mobile network operators’ infrastructure equipment
through the NB-IoT radio protocol (3GPP Rel-13). The following table shows the frequency bands of
BC95 series module.
Table 1: Frequency Bands of BC95 Series Module
BC95 is an SMD type module with LCC package, with an ultra-compact profile of 19.9mm × 23.6mm ×
2.2mm, which can be easily embedded into applications. It provides hardware interfaces such as ADC
and UART interfaces, and can meet almost all the requirements for IoT applications, such as smart
metering, bike sharing, smart parking, smart city, security and asset tracking, home appliances,
agricultural and environmental monitoring, etc.
Designed with power saving technique, the BC95 consumes an ultra-low current of 5uA in PSM (Power
Saving Mode).
The module fully complies with the RoHS directive of the European Union.
“*” means under development.
