Quectel BC95 Hardware Design

NB-IoT Module Series
BC95 Hardware Design
BC95_Hardware_Design Confidential / Released 38 / 51
5 Electrical, Reliability and Radio
Characteristics
5.1. Absolute Maximum Ratings
Absolute maximum ratings for power supply and voltage on digital and analog pins of the module are
listed in the following table.
Table 20: Absolute Maximum Ratings
5.2. Operating Temperature
The operating temperature is listed in the following table.
Table 21: Operating Temperature
Parameter
Min.
Max.
Unit
VBAT
-0.3
+4.25
V
Current of Power Supply
0
0.3
A
Voltage at Digital Pins
-0.3
+3.3
V
Voltage at Analog Pins
-0.3
+4.25
V
Voltage at Digital/Analog Pins in Power Down Mode
-0.25
+0.25
V
Parameter
Min.
Typ.
Max.
Unit
Operation Temperature Range
1)
-30
+25
+75
ºC
Extended Temperature Range
2)
-40
+85
ºC
