Quectel EG915U Series User Manual

LTE Standard Module Series
EG915U_Series_Hardware_Design 57 / 91
Table 27: Operating Frequency of EG915U-LA
Only EG915U-CN supports LTE-TDD.
5.1.3. Reference Design of Antenna Interface
A reference design of ANT_MAIN pin and ANT_BT/WIFI_SACN pin are shown as below. A π-type
matching circuit should be reserved for better RF performance. The capacitors are not mounted by
default.
Operating Frequency
Transmit (MHz)
Receive (MHz)
GSM850
824-849
869-894
PCS1900
1850-1910
1930-1990
EGSM900
880-915
925-960
DCS1800
1710-1785
1805-1880
LTE-B2
1850-1910
1930-1990
LTE-B3
1710-1785
1805-1880
LTE-B4
1710-1755
2110-2155
LTE-B5
824-849
869-894
LTE-B7
2500-2570
2620-2690
LTE-B8
880-915
925-960
LTE-B28
703-748
758-803
LTE-B66
1710-1780
2110-2200
NOTE
