6.5. Tx Power
Table 34: EG915U-CN RF Output Power
Frequency Bands
Max. RF Output Power
Min. RF Output Power
EGSM900
33 dBm ±2 dB
5 dBm ±5 dB
DCS1800
30 dBm ±2 dB
0 dBm ±5 dB
LTE-FDD
23 dBm ±2 dB
< -39 dBm
LTE-TDD
23 dBm ±2 dB
< -39 dBm
Table 35: EG915U-EU RF Output Power
Frequency Bands
Max. RF Output Power
Min. RF Output Power
GSM850/EGSM900
33 dBm ±2 dB
5 dBm ±5 dB
DCS1800/PCS1900
30 dBm ±2 dB
0 dBm ±5 dB
LTE-FDD B1/B3/B5/B7/B8/B20/B28
23 dBm ±2 dB
< -39 dBm
GSM900 PCL=5 @ 32.34 dBm
261
mA
GSM900 PCL=12 @ 19.06 dBm
112
mA
GSM900 PCL=19 @ 5.39 dBm
79
mA
DCS1800P CL=0 @ 29.89 dBm
187
mA
DCS1800P CL=7 @ 15.96 dBm
91
mA
DCS1800P CL=15 @ 0.95 dBm
72
mA
PCS1900P CL=0 @ 29.66 dBm
196
mA
PCS1900P CL=7 @ 15.59 dBm
94
mA
PCS1900P CL=15 @ 0.58 dBm
72
mA
