Quectel EG915U Series User Manual

LTE Standard Module Series
EG915U_Series_Hardware_Design 64 / 91
6.3. Operation and Storage Temperatures
Table 30: Operating and Storage Temperatures
Parameter
Min.
Typ.
Max.
Unit
Operating Temperature Range
6
-35
+25
+75
ºC
Extended Operation Range
7
-40
+25
+85
ºC
Storage Temperature Range
-40
+25
+90
ºC
6.4. Power Consumption
Table 31: EG915U-CN Current Consumption
6
Within operating temperature range, the module is 3GPP compliant.
7
Within extended temperature range, the module remains the ability to establish and maintain a voice, SMS, data
transmission, etc. There is no unrecoverable malfunction. There are also no effects on radio spectrum and no harm to radio
network. Only one or more parameters like P
out
might reduce in their value and exceed the specified tolerances. When the
temperature returns to the normal operating temperature levels, the module will meet 3GPP specifications again.
Voltage drop during
peak data rate
-
-
-
-
mV
I
VBAT
Peak supply current
(during transmission
slot)
Maximum power control
level at EGSM 900
-
1.7
2.5
A
USB_VBUS
USB connection
detection
-
3.5
5.0
5.25
V
EG915U-CN
Description
Conditions
Typ.
Unit
OFF state
Power down
32
µA
Sleep state
AT+CFUN=0 (USB disconnected)
1.0
mA
AT+CFUN=0 (USB connected)
2.2
mA
AT+CFUN=4 (USB disconnected)
1.0
mA
