Quectel LPWA Series Hardware Design

LPWA Module Series
BG950A-GL&BG951A-GL_Hardware_Design
37
/89
Figure 12: Reset Timing
3.10. PON_TRIG*
BG950A-GL & BG951A-GL modules provide one PON_TRIG pin which is used to wake up the module
from PSM*.
Table 11: Pin Definition of PON_TRIG
A reference circuit is shown in the following figure.
Pin Name
Pin No.
I/O
Description
Comment
PON_TRIG
96
DI
Wake up the module from PSM
1.8 V power domain.
