12
1. INITIAL CONSOLE PROGRAMMING
If an entry selection error is made during steps 1-6, place the AUTO/MAN/OFF switch
to the OFF position. Depress key and hold while placing the AUTO/MAN/OFF
switch to MAN or AUTO. This will "reset" the Console. The DATA display will now
show "US".
1) Display US (acres), SI [hectares],or TU {1000 sq. ft.}.
a) Depressing momentarily steps the DATA display from US to SI.
b) Depressing momentarily steps the DATA display from SI to TU.
c) Depressing momentarily steps the DATA display from TU to US.
2) Selecting US, SI, or TU.
a) To select US, SI, or TU, step until the desired code is displayed.
b) Momentarily depress , the DATA display will now display SP1.
3) Display SP1 (wheel drives, etc.) or SP2 (radar sensors).
a) Depressing momentarily steps the DATA display from SP1 to SP2.
b) Depressing momentarily steps the DATA display from SP2 to SP1.
4) Selecting SP1 or SP2.
a) To select SP1 or SP2, step with until desired code is displayed.
b) Momentarily depress , the DATA display will now display C-Sd.
5) Selecting C-Sd or C-FC.
a) To select C-Sd or C-FC, step with until desired code is displayed.
b) Momentarily depress , the DATA display will now display "0".
6) Procedure for entering BOOM CAL:
Definition of keys:
Depressing this key displays the selected boom number.
EXAMPLE: Boom 1 will display as b-01.
Depressing this key after selecting BOOM CAL increments the boom number.
EXAMPLE: b-01 will increment to b-02.
Depressing this key after selecting BOOM CAL decrements the boom number.
EXAMPLE: b-02 will decrement to b-01.
