Raven TC1 User Manual

CHAPTER
5
Cab Component Installation: RS1 Installation 27
CHAPTER 5 CAB COMPONENT
INSTALLATION
RS1 INSTALLATION
1. Install the RS1 mounting bracket to the suppled RS1 using the supplied 1/4” - 20 hardware.
FIGURE 1. RS1 Mounting Bracket
2. Use the provided 5/16” - 18 lock nuts to assemble the RS1 latch bracket on the cab mounting bracket.
FIGURE 2. RS1 Secured to Cab Mounting Bracket
