Appendix A: Technical Summary A-1
Appendix A: Technical Summary
Feature Description
CE Conforms to 89/336/EEC(EMC),
EN60945:1997
Y2K Compliant
Size 7.7in (195mm) x 4.33in (110mm) x 3.9in
(99mm), excluding trunnion
Weight 1.65 lb. (0.75 kg)
Environmental Waterproofing To CFR46; suitable for external mount-
ing
Temp Range, Operating: -10°C to +70°C
Temp Range, Storage: -40°C to +85°C
Humidity 20% to 95% RH
Mounting Trunnion (yoke) or panel
Power Input voltage 9.0VDC to 32.0VDC with reverse polar-
ity protection
Consumption <3W @12VDC (typical)
<6W @12 VDC with full backlighting.
Controls 8 defined keys, 4 soft keys and trackpad
Display type Film Super Twist Neumatic (FSTN) mono-
chrome LCD 240 x 160 pixels landscape
4 gray scales, 8 levels of backlighting,
100 levels of contrast
Display size 4½in (114.3mm) diagonal
Interfaces PWR/NMEA NMEA 0183 V2.30 receive and transmit
or RTCM input/NMEA 0183 V2.30
transmit (detailed in Appendix B )
Waypoint upload/download (WPL and
RTE)
SeaTalk Detailed in Appendix B
ANTENNA GPS active antenna
Position data GPS WAAS / EGNOS / MSAS ready
GPS receiver 12-channel, Internal 1575.42 Mhz (C/A code), L1
Time to first fix <8 seconds typical <45 seconds from cold start
(average)
