Chapter 6: Maintenance & Fault Finding 6-1
Chapter 6: Maintenance & Fault Finding
This chapter provides information on routine maintenance and on
possible causes of problems you may experience with your
Raychart 320 Chartplotter.
6.1 Maintenance
WARNING:
The chartplotter contains specialized circuits only accessible to
qualified service technicians - there are no user serviceable parts or
adjustments and the operator should not attempt to service the
equipment. The operator should not remove the rear cover.
Routine Checks
The chartplotter is a sealed unit. Maintenance procedures are therefore
limited to the following periodical checks:
• Wipe the display unit clean with a damp cloth.
• Examine the cables for signs of damage, such as chafing, cuts or nicks.
• Check that the cable connectors are firmly attached and that the con-
nections to the vessel’s DC power are clean and tight.
• Ensure that the cartridge cover is always fitted correctly.
Note: Never use chemical or abrasive materials to clean the chartplot-
ter. If the unit is dirty, wipe it with a clean, damp cloth.
EMC Servicing and Safety Guidelines
• Raymarine equipment should be serviced only by authorized Rayma-
rine service technicians. They will ensure that service procedures and
replacement parts used will not affect performance. There are no user
serviceable parts in this Raymarine product.
• Some products generate high voltages, so never handle the cables/con-
nectors when power is being supplied to the equipment.
• When powered up, all electrical equipment produces electromagnetic
fields. These can cause adjacent pieces of electrical equipment to inter-
act with one another, with a consequent adverse effect on operation. In
order to minimize these effects and enable you to get the best possible
performance from your Raymarine equipment, guidelines are given in
the installation instructions, to enable you to ensure minimum interac-
tion between different items of equipment, i.e. ensure optimum Elec-
tromagnetic Compatibility (EMC).
