Chapter 3: Operation 3-7
Nearest
➤ To obtain the information for the nearest port facility:
1. Move the cursor to the required position - this can be anywhere on the
chart and may be over an object.
2. Press
ENTER to display the object information pop-up.
3. Press the
NEAREST soft key. The port facility symbols are displayed.
4. Use the trackpad to highlight the required facility, then press
ENTER.
A list of the port(s) nearest to that facility is displayed, including dis-
tance and bearing to the port(s).
5. To find details for a facility, highlight a port name then press
ENTER.
6. Press
CLEAR to return to the port list.
7. Press
CLEAR again to return to the facility symbols.
8. Press
CLEAR once more to return to the default display.
3.3 Changing the Display Mode
The DISPLAY key is used to select the desired screen mode. The
following modes can be selected:
• Default Chart display
• GPS Data (four pages) / Waypoint Data (three pages)
• Boat Data (three pages) / Environment Data (two pages)
• Bearing & Distance Indicator (BDI) / Course Deviation Indicator
(CDI)
• Data Boxes
• Data Log
• Return to default Chart display
The modes that contain more than one page of data provide additional
soft keys which cycle through the pages. The highlighted soft key
indicates the screen mode currently displayed.
Note: Press the
DISPLAY key for at least two seconds in any display
mode to return to the Chart display.
Data Display Pages
In all graphical display pages, the steering instruction is STEER
STARBOARD
if the XTE is 0.01nm or more to port, STEER PORT if the XTE
is 0.01nm or more to starboard or
ON COURSE if XTE is less than 0.01 on
either side.
If no Goto or follow is in progress, the steering instruction is
NOT
FOLLOWING
and no steering arrows are shown.
81167_3.BOOK Page 7 Wednesday, November 21, 2001 2:12 PM
