Chapter 4: Setting Up the Chartplotter 4-1
Chapter 4: Setting Up the Chartplotter
4.1 Introduction
When you have installed your system and are familiar with its basic
operation, you may wish to set it up to operate according to your
requirements and display information according to your preferences.
This is achieved using the Set Up controls which are displayed when you
press the
MENU key. These settings can be changed at any time.
When you have set your preferences, they are retained until you reset
them; they are retained even when the unit is powered off.
This chapter provides instructions for displaying and changing the
factory default values to your preferences.
The set up parameters are divided into four sections:
• System, controlling overall functionality.
• Chart, controlling the chartplotting functions, including waypoint
information and vectors.
• Track, detailed in Using Tracks on page 47.
• GPS, displaying the GPS Navigation Status, selecting the GPS Fix
Mode or setting up a Differential GPS (DGPS).
The following sections list the parameters, their possible settings and
describe the function of each parameter in turn.
4.2 Changing the Set Up Parameters
➤ To set the default parameters:
1. Press the
MENU key to display the Set Up soft keys shown in
Figure 4-1. The options available depend upon the current operating
mode; the full range of options is shown when in Chart Mode.
Figure 4-1: Set Up Soft Keys
2. Press the soft key corresponding to the Set Up you require.
The requested Set Up menu is displayed, listing the parameters and
their current settings.
3. Use the trackpad up/down to move the highlight through the list.
Arrows are displayed at the top/bottom right-hand corner if you can
scroll the list to display further parameters.
SYSTEM
SET UP¬
CHART
SET UP¬
TRACK
SET UP¬
GPS
SET UP¬
D4918-1
81167_3.BOOK Page 1 Wednesday, November 21, 2001 2:12 PM
