Figure 3-23: New Waypoint Screen
3. The new waypoint is listed at the vessel’s current position or, if not
available, the cursor’s current position; The waypoint is named with
the next available number.
If required, edit the waypoint using the
LAT/LONG, SYMBOL and
NAME soft keys. Operation of these soft keys is identical to the SYM-
BOL, NAME
and POSITION soft keys described in Editing Waypoint
Details on page 3-23.
4. When editing is complete, press
ENTER to place the waypoint in the
waypoint list (or
CLEAR to abort the operation).
5. When complete, press
CLEAR as required to exit to the default dis-
play.
➤ To place a waypoint as Loran TDs:
1. Press
MARK, followed by the WAYPOINT LIST soft key; the Waypoint
List and associated soft keys are displayed as shown previously
(Figure 3-22):
2. Press the
MAKE NEW WAYPOINT followed by the LORAN TDs soft key;
the
WPT POSITION (LORAN TDs) screen is displayed, together with it’s
associated soft keys, see Figure 3-24.
Figure 3-24: Waypoint Position Screen (Loran TDs)
SYMBOL NAME LAT/LONG LORAN TDs
SYMBOL NAME
WPT 005
N 50°50^000
W 001°06^000W
POSITION
BRG 124°m
RNG 12.6nm
NEW WAYPOINT
D5518-1
CHAIN ASF1/ASF2 SET TD 1 SET TD 2
CHAIN 6731 - NELS Lessay
SLAVES Y - Z (24 -39)
TD 1 29138.0 us
TD 2 44713.8 us
ASF 1 +0.0
ASF 2 +0.0
WPT POSITION (LORAN TDs)
D5519-1
