2.1Handbookinformation
ThishandbookdescribestheinstallationandoperationofRaymarine
T-Seriesthermalcamerasaspartofamarineelectronicssystem.
Itprovidesanoverviewoffeaturesavailableandexamplesofthe
controlsused.
Thishandbookcoversmodels:T300,T303,T350,T353,T400,
T403,T450,T453,T460,T463,T470SCandT473SC.Itincludes
informationtohelpyou:
•planyourthermalimagingsystemandensureyouhaveallthe
necessaryequipment,
•installandconnectthethermalcameraasapartofyoursystem
ofRaymarineelectronics,
•operatethethermalcamerasystem,
•setupthethermalcamerasystemusingtheon-screenmenus,
•obtainsupportifrequired.
Thehandbookisforusewiththefollowingproducts:
•T300–QVGAThermalcamera
•T303–QVGAThermalcamera(30Hz)
•T350–VGAThermalcamera
•T353–VGAThermalcamera(30Hz)
•T400–QVGAdualpayloadcamera
•T403–QVGAdualpayloadcamera(30Hz)
•T450–VGAdualpayloadcamera
•T453–VGAdualpayloadcamera(30Hz)
•T460–VGAdualpayloadcamera
•T463–VGAdualpayloadcamera(30Hz)
•T470SC—VGAdualpayloadstabilizedcolorcamera
•T473SC—VGAdualpayloadstabilizedcolorcamera(30Hz)
Thermalcamerahandbooks
DescriptionPartnumber
T-Seriesthermalcamerasinstallationandoperation
handbook
Installation,commissioningandoperationinstructionsfor
T-Seriesthermalcamerasystems.
81338
2.2T-Seriesthermalimagingcameras
T-Seriesisamaritimethermalimagingsystemforuseonnearlyany
kindofvessel.Itprovidesaclearimageinlow-lightandno-light
conditions.Forexample,athermalcameracanhelpyounavigate
atnightoridentifyobstaclesinareasoflowvisibilityoreventotal
darkness.
D119 7 4-2
1
2
3
1.Thermalcameralenswindow
2.Visiblelightcameralenswindow
3.Gimbalassembly
TheT-Seriessystemhasthefollowingkeyfunctionsandfeatures:
•Pan,tiltandzoomoperations.
•Automaticcameraadjustmenttosuitchangingconditions.
•Presetmodes(Scenes)optimizedforprevailingconditions.
•Automaticwindowheaterstode-icethelenswindowincold
weather.
•Singleanddualpayloadcongurations.(T400,T403,T450,
T453,T460andT463aredualpayloadmodelswithboththermal
andvisiblelight(greyscale)capabilitytoenhancelowlight
performance.)
•TheT470SCandT473SCmodelsincludesamechanical
stabilizationfeaturewhichimprovesimagestabilityby
compensatingforvesselmotionandboththermalandcontinuous
zoomcolorvisiblelightcamera.
10T-Series
