“j
“,..
.,...
.
.
.
.
.
,.,,,,
_L1.^./
To connect your camcorder to a TV without audio/video inputs, you will need an
optional
lCVA147C
RF output adapter and an optional coaxial RF cable, such as
AH065G
or
AH066G
shown on page 3.
If your TV has AUDIO and VIDEO IN jacks
(or is connected to a VCR), refer to pages 46-47.
VHF
Ante1
h
0
z
Optional
Transformer
(Such as 193983)
Optional Coaxial
RF Cable
(such as
AH065G
or
AHO66G)
Back of TV
IiVFROMAhT
Connector
1
CH3/CH4
Switch
Optiokal
RF Output Adapter
(lCVA147C)
Installation
0
1
Disconnect the VHF antenna from
your TV. Connect the antenna to the
iN
FROM
ANT connector on the RF
output adapter if you are going to leave
the adapter connected to the TV.
Note: If your VI-W antenna is the flat
twin-lead type attached by two screws,
you
will
also need an optional 3OOff5 ohm
transformer,
such
as
193983 shown on
page 3.
48
OUT,
VIDEO Jacks
0
2
Attach one end of the optional coaxial
RF cable to the OUT TO TV connector
on the adapter, and attach the other end
to the VHF input on your TV as
shown.
Note:
If your TV has 300 ohm screw
terminals, you will need a 75/300 ohm
transformer, such as AH01 1,
shown on
page 3.
0
3 Attach the RF output adapter’s plug to
the AUDIO, RF DC OUT, and VIDEO
jacks located under the small cover on
the back of the camcorder.
To Next Page
