37
Appendix A: Connecting the Receiver
Things to know before
connecting the components
• Protect components from power surges.
• Connect all components before plugging any power
cords into the wall outlet.
• Always turn off the receiver and/or components before
you connect or disconnect any cables.
• Always make sure the color-coded plugs match the
color of the terminals in which they are inserted. The
connection cable plugs and jacks are color-coded
as follows:
Speaker Terminals Red for positive (+) terminals.
Black for negative (-) terminals.
RCA Phono Type Terminals Red for the right (R)
channel. White for the left (L) channel. Yellow for the
video (V). Black for the subwoofer. (Not Included)
• Some units may be supplied with connection plugs that
are color coded red and black instead of red and white.
In this case, the black plug takes the place of the
white plug.
• Contact Consumer Relations if you have questions
concerning the connections of components.
➣
➣
3
Operating the Receiver
2
First Things First
1
Tour of the receiver
3
➣
Programming the Remote
4
