Redarc RS Series User Manual

5
1 INTRODUCTION
1.1 Specifications
Model: R-12-1000RS-NA
Input
Characteristics
Max. Rated Input Current 105A
Voltage 12V DC
Over-Voltage Protection 16.5±0.3V DC
Under-Voltage Protection 10.5±0.3V DC
Voltage Range 10.5~16.5V DC
No Load Current ≤1.5A @ 12V DC
Power Saving Mode <0.1A @ 12V DC
Output
Characteristics
Continuous Output Power 1000W (VA) (±3%)
Maximum Output Power (1 min) >1000~1150W (VA) (100%~115%)
Surge Power (<3 sec) <1750W (VA)
Frequency 50/60Hz±0.5% (Dip Switch Selectable)
Output Voltage
100/110/115/120V AC (±5% )
(Dip Switch Selectable)
Efficiency Max 92%
Short-Circuit Protection 1 Sec Shutdown, Restart to Recover
Output Waveform
(1)
Pure Sine Wave (THD<5% @ Normal Load)
Signal and
Control
Remote Controller Panel Input REMOTE-RS (optional)
LED Indicator Red/Orange/Green LED
Dry Contact Terminal By a relay
Remote Control Terminal 6-port Green terminal (for inverter ON/OFF)
Protection
Input Protection
(2)
Over/Under Voltage, Reverse Polarity
(Internal Fuse)
AC Output Protection Short-Circuit, Overload
Others
Over/Under Temperature Protection (by heat
sink) Temperature 176°F (80°C) /−4°F (−20°C)
Environment
Operating Temp.
−4~104°F — Derates to 140°F
(–20~40°C — Derates to 60°C)
Storage Temp. –22~158°F (−30~70°C)
Storage Temp. and Humidity 10~95% RH
Safety and EMC
Safety Standards UL 458, C22.2 No. 107.1
EMC Standards
(3)
FCC Class B, CAN ICES-003 (B)/NMB-003(B)
Weight 7.2 lb (3.3kg)
Cooling Temperature and Load Controlled cooling Fan
Dimensions (W×H×D) 7.9"×3.3"×14.7" (200×83×372mm)
(1) Normal load condition: Vin=12.5V/25V/50V, Vo=100/110/115/120 V AC 80% load (PF=1.0)
(2) Reverse polarity connection can blow the internal fuse and may damage the inverter permanently.
(3) Refer to page 26 for compliance information.
