Renesas RA Family EK-RA6M5 v1 – User's Manual
R20UT4829EG0100 Rev. 1.00 Page 8 of 34
Mar.15.21
2. Kit Contents
The following components are included in the kit:
1. EK-RA6M5 v1 board
2. Micro USB device cable (type-A male to micro-B male)
3. Micro USB host cable (type-A female to micro-B male)
4. Ethernet patch cable
Figure 3. EK-RA6M5 Kit Contents
3. Ordering Information
• EK-RA6M5 v1 kit orderable part number: RTK7EKA6M5S00001BE
Note: The underlined character in the orderable part number represents the kit version.
• EK-RA6M5 board dimensions: 80 mm (width) x 180 mm (length)
