General| Architecture | ARM Cortex-R52 |
|---|---|
| Max CPU Frequency | 800 MHz |
| SPI | 4 channels |
| PWM | 16 channels |
| Operating Temperature | -40°C to +105°C |
| Package | BGA |
| Ethernet | Gigabit Ethernet |
| USB | USB 2.0 |
| CAN | CAN FD |
| I2C | 4x I2C |
| ADC | 12-bit ADC |
Explains the purpose of the RSK+ as an evaluation tool for Renesas microprocessors.
Lists the evaluation features provided by the RSK+, including programming and debugging.
Details the external voltage input requirements for the CPU board, including connectors.
Shows the top component layout of the development board with labels.
Provides the physical dimensions and connector positions of the board in mm.
Illustrates the internal board component connectivity to the MPU via a block diagram.
Shows diagrams for connecting external emulators and J-Link OB to the CPU board.
Details the function and connection of push and DIP switches on the CPU board.
Lists the 20 LEDs on the board, their colors, functions, and pin connections.
Describes the three Ethernet PHY ICs and their MPU connections for RGMII interface.
Explains solder bridges, trace cuts, and pin header jumper types and their default configurations.
Details option links and switch settings for configuring MPU boot and operating modes.
Details option links associated with configuring the external bus and NOR flash interfaces.
Details option links associated with configuring the Ethernet interface (ETH0, ETH1, ETH2).
Lists connections for application headers JA1-A, JA2-A, and JA3-A.
Lists connections for pin headers CN1, CN2, and CN3 for MPU pin access.
Explains MPU boot modes and configuration procedures and precautions.
