Table 6-19: External BUS & NOR Flash Configuration Option Links (3)
Signal name
MPU
MPU Peripheral Selection
Destination Selection
Pin
Port
Signal Fit DNF
Interface
/Function
Fit DNF
BSC_A01_CAN_TX P2 P05_3
BSC_A01
IC29.56
(SW6-1 = ON)
-
IC22.E1
-
-
IC23.23
-
-
JA3-A.2
-
-
CAN_TX
IC29.55
(SW6-1 = OFF)
-
CN1.18
-
-
JA5-A.5
-
-
U10.1
-
-
BSC_D15_M A3 P23_0 BSC_D15
IC28.25
(SW6-1 = ON)
-
IC22.F7
-
-
IC23.53
-
-
JA3-A.36
-
-
BSC_D14_SDA1 C6 P22_7
BSC_D14
IC28.33
(SW6-1 = ON)
-
IC22.H7
-
-
IC23.51
-
-
JA3-A.35
-
-
I2C_SDA_A
IC28.32
(SW6-1 = OFF)
-
J27.2
-
-
J30.3
-
-
J22.6
-
-
JA1-A.25
-
-
J26.4
E3
E24
BSC_D13_SCL1 E7 P22_6
BSC_D13
IC28.22
(SW6-1 = ON)
-
IC22.F6
-
-
IC23.50
-
-
JA3-A.34
-
-
I2C_SCL_A
IC28.23
(SW6-1 = OFF)
-
J27.1
-
-
J30.4
-
-
J22.5
-
-
JA1-A.26
-
-
J26.3
E2
E23
BSC_D12_M B5 P22_5 BSC_D12
IC28.36
(SW6-1 = ON)
-
IC22.G6
-
-
IC23.48
-
-
JA3-A.33
-
-
BSC_D11_M E8 P22_4 BSC_D11
IC28.19
(SW6-1 = ON)
-
IC22.H4
-
-
IC23.47
-
-
JA3-A.32
-
-
BSC_D10_ENCIF11 A4 P22_3
BSC_D10
IC28.39
(SW6-1 = ON)
-
IC22.G3
-
-
IC23.45
-
-
JA3-A.31
-
-
ENCIF11
IC28.38
(SW6-1 = OFF)
- CN1.14 - -
BSC_D09_TRACE_CLK F9 P22_2
BSC_D09
IC28.16
(SW6-1 = ON)
-
IC22.F3
-
-
IC23.44
-
-
JA3-A.30
-
-
TRACE_CLK
IC28.17
(SW6-1 = OFF)
- CN9.6 - -
BSC_D08_TRACE_CTL C7 P22_1
BSC_D08
IC28.42
(SW6-1 = ON)
-
IC22.H2
-
-
IC23.42
-
-
JA3-A.29
-
-
M2_POE
IC28.41
(SW6-1 = OFF)
SW6-4 = ON
SW6-3 = OFF JA5-A.16 - -
TRACE_CTL
IC28.41
(SW6-1 = OFF)
SW6-3 = ON
SW6-4 = OFF CN9.36 - -
BSC_D07_TRACE_D7 B6 P22_0
BSC_D07
IC28.11
(SW6-1 = ON)
-
IC22.G7
-
-
IC23.13
-
-
JA3-A.24
-
-
TRACE_D7
IC28.12
(SW6-1 = OFF)
-
CN9.16
-
-
CN3.8
-
-
BSC_D06_TRACE_D6 B7 P21_7
BSC_D06
IC28.47
(SW6-1 = ON)
-
IC22.E6
-
-
IC23.11
-
-
JA3-A.23
-
-
TRACE_D6
IC28.46
(SW6-1 = OFF)
-
CN9.18
-
-
CN3.7
-
-
