REPLIGEN XCell ATF10 User Manual

XCell
TM
ATF System with C410:V4B Controller User Guide
8
Table 4a. XCell™ ATF 10 Pump Housing Parts List
Note: C-CLAMP (Hemisphere) Items #20,21 should be torqued to 20-25 ft-lbs with 1" wrench flats
See Appendix 7 for list of spares and accessories
ITEM
M
NO.
DESCRIPTION
Material
QTY.
1
ASME Clamp, Assembly, XCell™
ATF10
316 SS
2
2
Pump Hemisphere Air Side,
XCell™ ATF10
SA479 316L SS
1
3
Lifting Handle, Assembly, XCell™
ATF10
316 SS
1
4
Pump Hemisphere Liquid Side,
Assembly, XCell™ ATF10
316 SS
1
5
Filter Housing Assembly, XCell™
ATF10
316 SS
1
6
Stand, Assembly, XCell™ ATF10
316 SS
1
7
Diaphragm, Pump, XCell™ ATF10
50A P.C. Silicone
1
8
0.295" C/S x 6.835" ID x 7.425" OD
O-Ring, 50A Hardness, Clear
Silicone
2
9
90 Degree Elbow, 1.5TC
316 SS
1
10
Sanitary Gasket, 1 1/2" TC
EPDM
5
11
Clamp, Sanitary, 1 1/2" TC
304 SS
5
12
Sanitary Gasket, 3/4" TC
EPDM
4
13
Sanitary Gasket, 1/2" TC
EPDM
3
14
Clamp, Sanitary 1/2-3/4" TC
304 SS
7
15
Sanitary Cap 3/4"
316 SS
2
16
Sanitary Diaphragm Valve, 1/2"
w/TC ends
316 SS
3
17
Window, Sanitary 1.5"TC
AISI Type 316LSS
2
18
Pressure Gauge, 1.5" TC, 30 psi
SS
1
19
45 deg Elbow, 3/4" TC
SS
1
20
C Clamp w/ Lock-B, Assembly,
XCell™ ATF10
316 SS
3
21
C Clamp w/ Lock-A, Assembly,
XCell™ ATF10
316 SS
3
22
Air Inlet Filter, 0.2 micron, 1/2" TC
Ends
PVDF
1
23
Instrument Tee, 1.5" x 2X 3/4" TC
316 SS
1
24
Reducer, XCell™ ATF10
SA479 316L SS
1
25
Spectrum F10 2 Micron PES
Hollow Fiber Cartridge
NA
1
26
3/8” Hex Bit Socket, 3/8” Drive
Alloy Steel
1
