IKONIC Tankless Water Heater Service Manual
71
WATER INLET CONNECTION
HOW TO REMOVE COMPONENTS
1. Remove 3 screws from the bottom plate, as pictured
below.
2. Remove a screw holding freeze protection heater
from water inlet connection, and pull the freeze pro-
tection heater.
3. Remove quick fastener connected to check valve.
NOTE: For non recirculation model, remove quick fas-
tener connected to water control valve.
Check Valve
NOTE: Before removing water inlet connection, turn off water to the water heater by closing the shut off valve and
drain the heater.
To Next Page
