3. 1

MODEM TEST START/< >

800Hz

4. Scroll through the available tests using > or < .

5. S

6. To stop the test: s

7. To finish: N FU

4.1.11. DTMF Tone Test (Function 08)

1. FU 6 1 9 9 5

then immediately Y

FUNCTION KPAD/NEXT

SERVICE FUNCTIONS

2. 0 8 Y

0-NCU 1-MODEM

2-DTMF

3. 2

DTMF TEST START/<>

TONE 0

4. Scroll through the available tests using > or < .

5. S

6. To stop the test: s

7. To finish: N FU

SERVICE TABLES AND PROCEDURES August 7th, 1995

SERVICE LEVEL FUNCTIONS

4-6

Overall Machine Information3
Specifications3
Component Layout7
Mechanical Components7
Drive Components8
Electrical Components9
Overall Machine Control11
Video Data Path12
Immediate Transmission12
Power Distribution15
Distribution Diagram15
Detailed Section Descriptions17
FCIP (Facsimile Controller and Image Processor)28
Video SRAM29
Installation31
Installing the Machine31
Initial Programming31
Service Tables and Procedures32
Service Level Functions32
DTMF Tone Test (Function 08)37
Operation Panel Test (Function 09)38
LED Array Test (Function 10)38
ADF Test (Function 10)39
Printer Test Patterns (Function 11)40
Printer Mechanism Test - Free Run (Function 11)40
Bit Switches43
Communication Parameters45
Printer Switches52
Communication Switches53
Ncu Parameters64
Default Settings80
Dedicated Transmission Parameters89
Service Ram Addresses92
Replacement and Adjustment100
Copy Quality Troubleshooting106
Mechanical Problems117
Error Codes123
Electrical Component Defects128
Defective Sensor Table128
