4.2.2. Scanner Switches
Scanner Switch 00
No FUNCTION COMMENTS
0
Not used Do not change the settings.
1
Not used Do not change the settings.
2
3
Maximum transmittable
document length
Bit 3 2 Setting
0 0 600 mm
0 1 1200 mm
1 0 14 m
1 1 Not used
If the user wants to send very long documents such as
well logs, select 14 m or a higher setting.
4
Not used Do not change the settings.
5
to
7
Not used Do not change the settings.
Scanner Switch 01 - Not used (do not change the settings)
Scanner Switch 02
No FUNCTION COMMENTS
0
to
7
Contrast threshold with
halftone disabled - Normal
setting
The value can be between 00 to 1F. For a darker
threshold, input a lower value.
Default setting - 0E[H]
Scanner Switch 03
No FUNCTION COMMENTS
0-7
Not used Do not change the settings
Scanner Switch 04
No FUNCTION COMMENTS
0-7
Not used Do not change the settings
Scanner Switch 05
No FUNCTION COMMENTS
0
to
7
Contrast threshold with
halftone enabled - Normal
setting
The value can be between 00 to 0F. For a darker
threshold, input a lower value.
Default setting - 07[H]
Scanner Switch 06 - 0F - Not used (do not change the settings)
SERVICE TABLES AND PROCEDURES August 7th, 1995
BIT SWITCHES
4-20
