Ricoh MP W6700 User Manual

1. Open the carrier sheet with the transparent sheet face up, and then insert the original also
face up.
Align the original with the fold of the carrier sheet.
BKV008S
2. Using both hands, hold the carrier sheet face down, and carefully insert the folded edge
of the carrier sheet into the insertion area.
DNB112
Setting the Original Hangers
The original hangers (optional) are useful when scanning two or more originals at a time.
Up to A1 (D) size originals can be placed on the hangers.
Attach each of the original hangers to the front of the machine.
Placing Originals
47

Ricoh MP W6700 Specifications

General

Warm-up time	120 seconds
Power source	220 - 240 V, 50/60 Hz
Print Speed	6.7 ppm (A1 horizontal)
Resolution	600 dpi
Maximum Print Width	914 mm
Media Types	Plain paper
Connectivity	USB 2.0, Ethernet 10/100/1000 Base-T
Dimensions	1, 250 x 755 x 1, 200 mm
Original Size	24 inches
Memory	512 MB
Paper weight	52 - 110 g/m²
Supported paper sizes	A4 - A0
Paper input capacity	2 rolls
