Ricoh P C600 User Manual

A3
EAG386
8. Pull out the jammed paper carefully, and then return the "A3" lever to its original position.
9. Push the area marked "PUSH" to close the rear cover.
Paper Misfeed Message (C) (D)
Remove the jammed paper from the bypass tray.
・
Remove the paper from
the bypass tray.
・
Pull the tray carefully
until it stops, lift the
front side of the tray,
and then pull it out of
the printer.
・
Lower the lever.
・
Pull out the jammed
paper carefully.
・
Lift the lever until it clicks.
・
Lift the front side of the tray,
and then slide it into the printer
carefully until it stops.
1 2 3 4
EAG387
• To avoid paper jams, make sure the tray is securely inserted.
Paper Misfeed Message (Y1) (Y2) (Y3)
Remove the jammed paper from the optional paper feed unit.
The following messages are displayed according to the tray where the paper is jammed:
• " (Y1)": Tray 2
• " (Y2)": Tray 3
• " (Y3)": Tray 4
The procedure for removing jammed paper is the same for all trays. In the following procedure, a paper
jam that occurs in Tray 2 (with the (Y1) message displayed) is explained as an example.
Removing Jammed Paper
119

Ricoh P C600 Specifications

General

Type	Original
Printing colors	Black
Quantity per pack	1 pc(s)
Built-in drum unit	-
Brand compatibility	Ricoh
Black toner page yield	18000 pages
Print technology	Laser printing

Weight and Dimensions

Package type	Box
Package weight	379 g
