Connecting the Telephone Line

1. Plug one end of the telephone line to the LINE jack at the left end of the

rear panel.

2. Plug the other end of telephone line to the “RJ-11” telephone jack

provided by the telephone company.

Connecting the Power and Turning on the Machine

1. Press the power switch to the “0” position to turn off the product.

2. Connect the small end of the power cable to the power (24Vdc/2.0A) jack

of the product

3. Connect the other end to an appropriate power outlet.

4. Press the power switch to the “I” position to turn on the product. After

showing the booting up message, the LCD display prompts the preset

ready status.

Note:

You can press the Energy Saver button on the control panel to switch to

the power saving mode. If the product is idle for 15 minutes (default

setting), it automatically shuts off the scanning lamp. Press any key

except the Power Saving button to return to the ready status.

24Vdc/2.0A Jack

Line Jack
