Placing Originals
This section describes the types of originals you can set and how to place them.
About Originals
Recommended size of originals
Exposure glass
• Up to 216 mm (8.5 ") in width, up to 297 mm (11.7 ") in length
Unscannable image area
Even if you correctly place originals, margins of a few millimeters on all four sides of the original may not
be scanned.
Margins when using exposure glass
1. Approx. 4.1 mm (0.2 inches)
2. Approx. 3 mm (0.1 inches)
3. Approx. 4 mm (0.2 inches)
Placing Originals on the Exposure Glass
• Do not place originals until all correction fluid or toner becomes completely dry. Doing so may
create marks on the exposure glass that will appear on copies.
Placing Originals
29
