Ricoh SP 5310DN User Manual

Loading Paper into the Bypass Tray
• For details about trays that can be loaded for each paper size and type, see page 48 "Paper Size
Specifications" and page 51 "Paper Type Specifications".
• Make sure the paper stack does not exceed the upper limit mark. Excessive stacking can cause
paper jams.
• Do not mix different types of paper.
• After loading paper, specify the paper size and type using the control panel. When printing a
document, specify the same paper size and type in the printer driver as specified on the printer.
• When loading label paper, load it one by one.
• Paper feeding conditions and printing quality may vary depending on the paper thickness and
width. Be sure to perform test printing using the same paper beforehand.
1. Open the bypass tray.
DPL019
Pull the extender out when loading A4 , 8
1
/
2
× 11 or larger paper.
DPL020
2. Loading Paper
60

Ricoh SP 5310DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.2, PDF 1.3, PDF 1.4, PDF 1.5, PDF 1.6, PDF 1.7, PDF 1.7+, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (printing)	- W
Total input capacity	- sheets
Maximum input capacity	2600 sheets
Processor family	Intel® Celeron®
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper, Transparencies
Paper tray media weight	64 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Network ready	-
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
Product color	White
Cables included	AC

Weight and Dimensions

Depth	410 mm
Width	420 mm
Height	345 mm
