Ricoh SP 8400DN User Manual

2. Loading Paper
This chapter describes available trays for each paper size and type, and explains how to load paper in
paper trays.
Loading Paper
Precautions for Loading Paper
• When loading paper, take care not to trap or injure your fingers.
• Do not stack paper over the limit mark.
• While Mailbox or the Internal Multi-Folding unit is attached, pull out only one paper tray at a time.
• To prevent multiple sheets from being fed at once, fan the paper before loading it.
• If you load paper when only a few sheets of paper remain in the tray, multiple sheet feeding may
occur. Remove any remaining paper, stack them with the new sheets of paper, and then fan the
entire stack before loading it into the tray.
• Straighten curled or warped paper before loading.
• For details about the paper sizes and types that can be used, see page 51 "Recommended
Paper Sizes and Types".
• You might at times hear a rustling noise from paper moving through the machine. This noise does
not indicate a malfunction.
Loading Paper into Paper Trays
Every paper tray is loaded in the same way.
In the following example procedure, paper is loaded into Tray 2.
• Check the paper edges are aligned at the right side.
• If a paper tray is pushed vigorously when putting it back into place, the position of the tray's side
fences may slip out of place.
43

Ricoh SP 8400DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	2.2 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Printing colors	Black
Maximum duty cycle	300000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3, RPCS
Internal memory	2048 MB
Processor frequency	1460 MHz
Total input capacity	- sheets
Maximum input capacity	4700 sheets
Duplex media weight	52 - 256 g/m²
Paper tray media types	-
Paper tray media weight	60 - 300 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5, B6
Maximum ISO A-series paper size	A3
Cabling technology	10/100/1000Base-T(X)
Security algorithms	SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	RJ-45
Optional connectivity	USB 2.0, Wireless LAN
Product color	Grey, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1780 W
Power consumption (ready)	43.4 W
Power consumption (printing)	- W
Energy Star Typical Electricity Consumption (TEC)	2.672 kWh/week
Mac operating systems supported	Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 8.1, Windows Vista

Weight and Dimensions

Depth	653 mm
Width	587 mm
Height	720 mm
Weight	57000 g
