Ricoh SP 8400DN User Manual

Removing Jammed Paper
• The inside of the machine could be very hot. Do not touch the parts with a label indicating the
"hot surface." Otherwise, an injury might occur.
• Some of this machine's internal components get very hot. For this reason, take care when
removing misfed paper. Not doing so could result in burns.
• When removing jammed paper, make sure not to trap or injure your fingers.
• To prevent misfeeds, do not leave any torn scraps of paper inside the machine.
• If paper jams continue to occur, see page 69 "When You Have Problems Operating the Machine"
and page 83 "Other Printing Problems" for details about how to solve the problem. If the actions
recommended in this manual fail to eliminate the problem, contact your service representative.
• If the error message remains displayed even after you remove misfed paper, fully open the front
cover, and then close it.
• When removing jammed paper, you can touch only those areas explicitly indicated in the manual.
• Do not remove the fusing unit. Doing so will result in loss of print quality.
• To remove paper that has not been fed into the fixing section correctly, remove the jammed paper
through the underside of the fusing unit. If the jammed paper cannot be removed through the
underside of the fusing unit, remove it from the top.
• When clearing paper jams from the mailbox, open the right cover all the way and hold it with your
hand. Releasing the right cover while it is open may damage the band that holds the right cover.
• Inside the finisher, or inside the front cover, there are stickers or sheets explaining how to remove
misfed paper.
• If a detailed removal instruction appears on the right of the screen, follow it.
• You can also use the procedure indicated in the [Check Status] screen to remove jammed paper.
Locating Jammed Paper
If a misfeed occurs, remove the jammed paper by following the procedures indicated in the animation
that appears on the screen and the sticker or sheet inside the front cover.
A misfeed has occurred in the place corresponding to the letter displayed on the control panel.
3. Troubleshooting
92

Ricoh SP 8400DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	2.2 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Printing colors	Black
Maximum duty cycle	300000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3, RPCS
Internal memory	2048 MB
Processor frequency	1460 MHz
Total input capacity	- sheets
Maximum input capacity	4700 sheets
Duplex media weight	52 - 256 g/m²
Paper tray media types	-
Paper tray media weight	60 - 300 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5, B6
Maximum ISO A-series paper size	A3
Cabling technology	10/100/1000Base-T(X)
Security algorithms	SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	RJ-45
Optional connectivity	USB 2.0, Wireless LAN
Product color	Grey, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1780 W
Power consumption (ready)	43.4 W
Power consumption (printing)	- W
Energy Star Typical Electricity Consumption (TEC)	2.672 kWh/week
Mac operating systems supported	Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 8.1, Windows Vista

Weight and Dimensions

Depth	653 mm
Width	587 mm
Height	720 mm
Weight	57000 g
