RIGOL Chapter 2 Performance Verification Test
2-18 RSA3000 Performance Verification Guide
Compare the calculation result with the specification.
13. Set the output frequency of Signal Generator A to 1 GHz; set the amplitude to -10 dBm. Set the
output frequency of Signal Generator B to 1.0002 GHz; set the amplitude to -10 dBm.
14. Replace the 300 MHz low-pass filter connected with Signal Generator A with a 1 GHz low-pass
filter. Repeat Step 4-7 (In Step 5 and Step 6, the frequency of the power is set to 1 GHz and
1.0002 GHz respectively).
15. Keep other settings unchanged. Set the center frequency of the spectrum analyzer to 1 GHz; set
the span to 1 kHz. Repeat Step 8-10.
16. Exchange the output settings of the two signal generators. Set the center frequency of the
spectrum analyzer to 1.0004 GHz. Press Single and wait for the instrument to finish a sweep.
Then press Peak and record the delta result. Repeat Step 10.
Test Record Form
Center Frequency
Delta
Calculation
Result
[1]
Limit
Pass/Fail
299.8 MHz
>10 dBm, >+15 dBm (typical)
300.4 MHz
999.8 MHz
1.0004 GHz
Note
[1]
: Calculation Result = -20 dBm - Delta/2 (-20 dBm is the level input into the mixer).
