31
REPLOT
START
REPLOT
START START
REPLOT
START CLEAR
Change Pinch
Roller Position
If a pinch roller is positioned over an area where there is no grit roller, the
message shown at right appears when you press the [ENTER] key.
If this occurs, lower the sheet loading levers and move the pinch rollers to the
proper positions above the grit rollers.
Reposition the material to match this new alignment, then lift the sheet loading
levers to hold the material in place.
When detecting the material size in step 4, if the material is misaligned and looks like it might come loose from the pinch rollers, or
actually does come loose, please reload the material.
5-5 Repeating the Same Cutting
The “Replot” feature allows you to create numerous copies of same cutting.
1
Press the [MENU] key to enter the menu mode, use
the [
] key to select [REPLOT], then press the [ ]
key to display the replot execution screen.
2
Pressing the [ENTER] key starts replotting.
The Replot function calls up all data in the data buffer and performs cutting with this data. When performing replotting, follow the
steps below to delete the data in the data buffer before send the data to be replotted from the computer.
1
Carry out step 1 above.
2
Use the [ ] and [ ]keys to select [CLEAR] and
press the [ENTER] key to delete the data in the data
buffer.
3
Use the [ ] key to leave the menu mode.
