111
Chapter 6 - Detailed Description of Functions
6-4. Detailed Description of the Menus
ACCELERATION
Saved Yes
Setting 0.05 G, 0.1 G
Default 0.1 G
This makes the setting for the quality of text engraving. When this is set to [0.05G], cutting times become longer, but the quality
of text engraving is improved.
COMP-X COMP-Y
Saved Yes
Setting 99.90 to 100.10%
Default 100.00
This corrects for movement distance along the X and Y axes.
REVOLUTION TIME
This displays the working time of the spindle motor. Use it as a guide for determining the service life of the spindle unit.
[SELF] Submenu
SURFACE CUT
This performs surfacing to adjust the flatness and parallelism of the table surface. Before you execute this, make the following
settings.
• Setting for the Home Position: Set the home position at the front-left corner of the table (the limit position for the X and Y axes).
• Setting for the Z0 Position: Set the Z0 position at the surface of the table.
It is assumed that you are performing this operation using a ZEC-A4430 cutter from Roland DG Corp. The cutting-in depth is 0.2
mm (0.0008 in.), the amount of cut-out is 1 mm, the feed rate is 30 mm/s, and the spindle speed is 20,000 rpm.
To Next Page
