Roland FR-8X User Manual

Selecting Parameters
117
5. When you want to end the Ad-Hoc mode connection,
restore the iPhone settings in [Settings] g [Wi-Fi] g
[Choose a Network] to their previous state.
NOTE
The Ad-Hoc Mode ON g OFF setting will take eect after you’ve
turned the unit o, then back on again.
Checking the IP Address and MAC Address
(WIRELESS INFO)
Here’s how to check the IP address and MAC address.
1. Select the [MENU] button g “17 Wireless” g“17.1 Wireless
I n f o ”.
MEMO
The MAC address shows the value indicated on the bottom of
the wireless USB adapter (WNA1100-RL; sold separately).
How to Save System Parameters
1. Modify all parameters you would like to use.
2. Press and hold the [MENU/WRITE] button to jump to the
“Write” page.
The display shows the following page.
3. Use the [DATA/ENTER] knob to select “System”.
4. Press [WRITE] to proceed.
The following page appears:
5. Use the [DATA/ENTER] knob to select the group of data
you need to save.
At default all group are selected (“Yes”).
6. Press the [WRITE] button to save the parameter groups.
After a while the display briey conrms the operation and the
returns to the main page.

Roland FR-8X Specifications

General

Manual	Yes
Operating time	8 h
Battery voltage	24 V
Battery capacity	4500 mAh
Power source type	Battery
Display type	LCD
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	2
Type	Piano accordion
Keys quantity	41 keys
Tones quantity	16
Tuning presets	Alpine, American L/H, Classic, D-Folk L/H, Dry, F-Folk, French, German L/H, Italian L/H, North Europe, Off, Scottish
RMS rated power	50 W
Speaker diameter	90 mm
Bass reed quantity	5
Drum sets quantity	18
Chord reed quantity	3
Treble reed quantity	7
Organ sounds quantity	32
Number of bass buttons	120 buttons
User programs quantity	1400
Maximum polyphony (notes)	128
Orchestral sounds quantity	180
Reverberation effects quantity	8
Adjustable tone range (octaves)	-1 - 3
Bellows resistance adjustment range	-63 - 64
Housing color	Red

Weight and Dimensions

Depth	280 mm
Width	543 mm
Height	415 mm
Weight	12100 g
