Roland FR-8X User Manual

Selecting Parameters
121
Performance memories per List
1400: 100 User Program Bank x 14 registers
AUDIO PLAYER and AUDIO RECORDING
Media
USB Flash memory
Audio Recorder Save format
Audio les (WAVE 44.1 kHz, 16-bit linear), MIDI les (SMF)
Audio Loop Function
REC (with Overdub function) and Play
OTHER FUNCTION
Accordion, Orchest1/Organ
Orchest2, Drum
Zone, High, Low
Octave
-1, 0, +1 for Treble, -3, 0, +3 for Orchest1, Orchest2
Orchestra Chord Guitar Mode
Gtr Table1, Gtr Table2, Gtr Table3
Sound Edit
Orchest1, Orchest2, Orch Bass, Orch Chord, Orch Free Bass
Speakers O
Yes
Additional switches
6 user assignable function switches on last row of bass buttons
PANEL CONTROLS
Encoder
Data Edit with Enter
Knob controls
Volume, Balance, Reverb Chorus, Delay, Eect (assignable)
Registers
14 Right Hand registers
7 Left Hand registers
Navigation switches
Up, Down, Menu/Write, Exit/Jump
Chin switches
3 programmable chin switches
Other switches
Set Up, Set Down, Orch 1 On/O, Orch 2 On/O, Organ On/O, Accordion On/O, Orch Bass On/O, Orch
Chord/Free Bass On/O, Free Bass On/O, Bass&Chord On/O, Drums On/O, Bass to Treble On/O, User
Program On/O, Song List On/O, Power On/O, Charge On/O, Loop/Wave/MP3 player: Loop, Reset/Stop,
Play/Pause, Audio Rec
CONNECTORS
Audio OUTPUT jacks (R, L/Mono)
1/4” phone type
PHONES jack
Stereo 1/4” phone type
MIDI connectors
IN, OUT
USB ports
USB COMPUTER connector (Type B, reception and transmission of MIDI data)
USB MEMORY (Type A, data storage devices)
GENERAL SPECIFICATION
Power supply
AC adaptor (PSB-14U adaptor)
Current Draw
3750 mA
Auto O function
Disable, 10, 15, 20 minute
Dimensions
Piano type: 415 (H) x 543 (W) x 280 (D) mm;
16-3/8 (H) x 21-7/16 (W) x 11-1/16 (D) inches
Button type: 410 (H) x 510 (W) x 260 (D) mm;
16-3/16 (H) x 20-1/8 (W) x 10-1/4 (D) inches
Weight
Piano type: 12,1 Kg, 26 lbs 11 oz without straps
Button type: 11,9 Kg, 26 lbs 4 oz without straps
SUPPLIED ACCESSORIES
Owner’s Manual
PSB-14U AC adaptor,
Power cord (for connecting the AC adaptor)
Rechargeable Ni-MH battery pack (BP-24-45)
Reference caps for the bass buttons
Reference buttons for the treble keyboard (only for FR-8X button type)
Straps
Accordion Cloth
Accordion soft bag
OPTIONS
USB
USB ash memory (M-UF-series)
Wireless USB Adaptor (WNA1100-RL)
Headphone
Roland RH Series
MIDI Foot Controller
FC-300
NOTE
In the interest of product improvement, the specications and/or appearance of this unit are subject to change without prior notice.

Roland FR-8X Specifications

General

Manual	Yes
Operating time	8 h
Battery voltage	24 V
Battery capacity	4500 mAh
Power source type	Battery
Display type	LCD
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Headphone outputs	1
USB connector type	USB Type-A, USB Type-B
USB ports quantity	2
Type	Piano accordion
Keys quantity	41 keys
Tones quantity	16
Tuning presets	Alpine, American L/H, Classic, D-Folk L/H, Dry, F-Folk, French, German L/H, Italian L/H, North Europe, Off, Scottish
RMS rated power	50 W
Speaker diameter	90 mm
Bass reed quantity	5
Drum sets quantity	18
Chord reed quantity	3
Treble reed quantity	7
Organ sounds quantity	32
Number of bass buttons	120 buttons
User programs quantity	1400
Maximum polyphony (notes)	128
Orchestral sounds quantity	180
Reverberation effects quantity	8
Adjustable tone range (octaves)	-1 - 3
Bellows resistance adjustment range	-63 - 64
Housing color	Red

Weight and Dimensions

Depth	280 mm
Width	543 mm
Height	415 mm
Weight	12100 g
