Roland V-combo VR-730 User Manual

6
Panel Descriptions
Front Panel
1
2 3 4
5
6
7
8
9 10
11
12
13 14
15
Number Name Explanation Page
1
USB MEMORY port
Connect a USB ash drive (sold separately) here.
You can save or play back songs you’ve recorded, and save or load registration sets.
If you connect a wireless USB adapter (sold separately: WNA1100-RL or equivalent), you’ll be
able to use applications that support wireless.
* The VR-730’s USB MEMORY port is located at the right side of the rear panel.
p. 34
p. 41
p. 55
2
D-BEAM controller
You can apply various eects to the sound by positioning your hand above the D-BEAM controller.
[PITCH] button If this is on, the D-BEAM controller will control the pitch.
p. 25[SFX] button If this is on, the D-BEAM controller will control the sound eects.
[CONTROLLER] button If this is on, the D-BEAM controller will control the eect you’ve assigned.
3
Eect section
Here you can apply eects to the sound.
[OVERDRIVE] knob Applies a distortion eect.
p. 24
[TONE] knob Adjusts the tonal character.
[COMPRESSOR] knob Makes the sound more consistent.
[MFX] knob Applies a multi-eect (multiple eects).
[DELAY] knob Delays the sound to create an echo-like eect.
[REVERB] knob Applies reverberation to the sound.
4
Organ section
Here you can select organ sounds. You can also create your own organ sounds, and adjust the volume.
Harmonic bars
Use these to shape the organ sound.
You can modify the sound in real time as you play.
p. 17
[LEVEL] bar Adjusts the volume of the organ section. —
[TYPE] button Selects the variation of organ sounds. p. 13
ORGAN [SPLIT] button Divides the organ into two keyboard regions. p. 29
[UPPER/LOWER] button Selects the part when using the harmonic bars to shape the sound. p. 29
[PERCUSSION] button Turns the percussion eect of the organ sound on/o. p. 21
[VIBRATO/CHORUS] button Turns the vibrato or chorus eect of the organ sound on/o. p. 22
5
Display
Display Sound names and other settings are shown here. —
6
MODE [ORGAN] button Allows you to play organ sounds. p. 13
MODE [PIANO] button Allows you to play piano sounds. p. 14
MODE [SYNTH] button Allows you to play synthesizer sounds. p. 14
* The illustration shows the VR-09.

Roland V-combo VR-730 Specifications

General

Equalizer	Yes
Product type	Digital synthesizer
Product color	Black
Sound effects	Compression, Delay, Overdrive, Reverberation
Sound effects quantity	268
Keyboard number of keys	73
Maximum polyphony (notes)	128
Reverberation effects quantity	6
USB ports quantity	2
6.35 mm (1⁄4-inch) input	1
Battery type	AA
Operating time	5 h
Power source type	AC, Battery
Number of batteries supported	8

Weight and Dimensions

Depth	366 mm
Width	1215 mm
Height	124 mm
Weight	9900 g
